GILDEMEISTER - CTX 420 linear V6
- Main and sub spindle
- Tool drive
- C axis / Y axis
- Partial hollow clamping device
- ShopTurn - Surface
- Package bar processing consisting of:
- Hollow clamping device 66mm
- Workpiece picking device
- Incl. 2x driven tools
- Incl. 4x double tool holders
- Incl. 4x tool holders
- Incl. 83x tools
Type: CTX 420 linear V6
Control: 840D powerline Siemens
Country of origin: Germany
Delivery time: to be agreed
Quotation: ex site
turning diameter: max. 560 mm
turning length: 600 mm
control: 840D powerline Siemens
greates pass round over bed: 680 mm
Swing dia. over traverse guideway: 565 mm
centre distance: 620 mm
turning speed range - main spindle: 20 - 5.000 min/-1
power capacity - main spindel: 25 / 37 kW
max. Torque: 213 Nm
spindle nose: 140H5
spindle bearing diameter: 90 mm
usable bar diameter: 65 mm
max. chucking diameter: 250 mm
C-Axis: 0,025° / 360 °
Spindle speed range subspindle: 20 - 7.000 min/-1
power capacity - Sub spindle: 25 / 33 kW
spindle bore: 57 mm
number of toolpositions: 12 pos
Number of driven toolspositions: 12 pos
Spindle speed - driven tools: max. 4.500 min -1
power capacity - driven tools: 12,2 kW
tool taper: VDI 40 DIN 69880
Tool dimensions with square shank: 40 mm
x-axis: 185 mm
y-axis: 80 (+40 / -40) mm
z-axis: 620 mm
rapid traverse: Z: 45 m/min
total power requirement: 50 kVA
Coolantsystem: 980 L, 8 und 20 bar
oil mist extraction: Vorbereitung / Prep
